Asphalt Reinforcement Pavement Geogrid

Payment Type: L/C,T/T,D/P
Incoterm: FOB,CFR,CIF,FCA,CPT
Min. Order: 10000 Square Meter
Delivery Time: 7 Days

Basic Info


Model No.: 30/30-30,50/50-30,100/100-30 30/30-50,50/50-50,100/100-50

Material: Polyester

Polyester Geogrid With Nonwoven 1-6m: 30/30-30,50/50-30,100/100-30 30/30-50,50/50-50,100


Additional Info


Packaging: PE Bags And Colored Tapes

Productivity: 500,000.00 sqm per day

Brand: Lianyi Geosnthetics

Transportation: Ocean,Land,Air

Place of Origin: CHINA

Certificate: ISO CE IGS IECA SGS TRI SGI


Product Description

                          Asphalt Reinforcement Pavement Geogrid





Product Introduction



Asphalt Reinforcement Pavement Geogrid is a new composite geosynthetic material which is made of fiberglass yarns or polyester yarns and geotextile and sewing together by Germany made warp-knitting machine



Product Function


It can widely apply in the water conservation, the municipal administration,  the building, the transportation,  the subway,  the tunnel,  the environmental protection and so on.


Specification



Material Properties

Unit







Test Method

Unit Weight

g/m2

270+/-10

500+/-20

520+/-20

ASTM D-5261

Aperture Size

mm

     25.4x25.4      40x40

Measured

Open Area of Grid

%

              80

CWO 22125

Tensile Strength (MD)

KN/m

50

100

120

ASTM D-6637

Tensile Strength (CMD)

KN/m

50

100

120

ASTM D-6637

Elongation at Break

%

             <10

ASTM D-6637

Shrinkage @ 375° F for 15 min

%

             <1



Melting Point

° C

             255

ASTM D-276

Roll Size

 m

2x100m,2.5x100m,3.95x100m,5x100m



Our Main Products:

Fiberglass Geogrid,Polyester Geogrid,Nonwoven Geotextile,PP Biaxial Geogrid,Fiberglass Geogrid,Polyester Geogrid,Asphalt Reinforcement Geocomposite,Woven Geotextile,HDPE Geocell,HDPE Geonet,Drianage Geocomposites,Fiberglass Mesh,Spunbond Nonwoven Fabric,etc
