Polyester Geogrid Knitting With Geogtextile Composites

Payment Type: L/C,T/T,D/P
Incoterm: FOB,CFR,CIF,FCA,CPT
Min. Order: 10000 Square Meter
Delivery Time: 7 Days

Basic Info


Model No.: 50-50KN,60-60KN,70-70KN,80-80KN,90-90KN,100-100KN, 105-105KN,115-115KN,120-120KN,150-150KN,200-200KN

Material: Polyester

Polyester Geogrid With Nonwoven 1-6m: 30/30-30,50/50-30,100/100-30 30/30-50,50/50-50,100

Name: Asphalt Reinforcement Polyester Geogrid Knitted Wi


Additional Info


Packaging: PE Bags And Colored Tapes

Productivity: 500,000.00 sqm per day

Brand: Lianyi Geosynthetics

Transportation: Ocean,Land,Air

Place of Origin: CHINA

Certificate: ISO CE IGS IECA SGS TRI SGI


Product Description

        Polyester Geogrid Knitting With Geogtextile Composites


Product Introduction

Polyester Geogrid Knitting With Geogtextile Composites is Polyester Geogrid Stitched With Nonwoven Geotextile Coated By Bitumen is an asphalt reinforcement composite that High density Polyester geogrid with light weight  PET Spunbond Nonwoven Fabric . It's an Asphalt Reinforcement Polyester Composites,they are stitched together and coated by bitumen to strengthen the bond with the asphalt layers . The asphalt layer to increase the tensile strength to prevent road surface crack caused by foundation crack reflection. The chemistry stability is good, the hot-stability is good, anti-weary dehiscence, anti-low temperature shrinkage crack, postponement reduction reflection crack.


Product Function


Asphalt Reinforcement Polyester Geogrid can widely apply in the water conservation, the municipal administration, the building, the transportation, the subway, the tunnel, the environmental protection and so on.


Specification


Material Properties

Unit







Test Method

Unit Weight

g/m2

270+/-10

500+/-20

520+/-20

ASTM D-5261

Aperture Size

mm

     25.4x25.4      40x40

Measured

Open Area of Grid

%

              80

CWO 22125

Tensile Strength (MD)

KN/m

50

100

120

ASTM D-6637

Tensile Strength (CMD)

KN/m

50

100

120

ASTM D-6637

Elongation at Break

%

             <10

ASTM D-6637

Shrinkage @ 375° F for 15 min

%

             <1



Melting Point

° C

             255

ASTM D-276

Roll Size

 m

2x100m,2.5x100m,3.95x100m,5x100m
